DuraClik
These wire-to-board connectors are designed for nearly any application. The audible, secure locking mechanism ensures secure mating while the secondary lock provides high retention for rugged environments. This system is available in 2 to 15 circuit single row configurations with both vertical and right-angle orientations.
Resources
| Spotlight Products | Description | Mates With | Use With |
|---|---|---|---|
| 502352-0200 | DuraClik Wire-to-Board Header, Single Row, Right-Angle, 2 Circuits, Tin (Sn) Plating | 502351-0200 | 560085-0101 50212-8000 |
| 560020-0320 | DuraClik Wire-to-Board Header, Single Row, Vertical, 3 Circuits, Tin (Sn) Over Nickel | 502351-0300 | 560085-0101 50212-8000 |
| 502352-0500 | DuraClik Wire-to-Board Header, Single Row, Right-Angle, 5 Circuits, Tin (Sn) Plating | 505151-0501 | 505153-8000 505152-0200 |
MX150
The MX150 Connector System has a compact design that offers a smaller footprint compared to traditional USCAR connectors and is engineered for easy and secure assembly. Customers demand a reliable, robust, and proven connector design for 48V wiring applications. The MX150 Mid-Voltage Connectors are an enhanced version of the MX150 design, that supports voltage ratings up to 60V. Additionally, for more powerful, high-performance motors using oil cooling, the MX150 Pass-Through Sealed Connectors are specifically designed to support oil-cooled electric motor technology, featuring a sealed, oil-resistant design.
Resources
| Spotlight Products | Description | Mates With | Use With |
|---|---|---|---|
| 33472-0606 | MX150 Mat-Sealed Female Connector Assembly, Dual Row, 6 Circuits, Keying Option A, with Connector Position Assurance | 75900-1401 | n/a |
| 34830-0801 | MX150 2x4 Dual Row Right-Angle Header, 8 Circuits, Keying Option A, Solder Tail | 33482-4801 | 33000-0001 34345-0001 |
| 33472-4806 | MX150 Mat-Sealed Female Connector Assembly, Dual Row, 8 Circuits, Keying Option A, with Connector Position Assurance | 34840-4410 | 33000-0001 |
Mini50
When space is a concern, the Mini50 single and dual-row connectors rise to the challenge with smaller pins, terminals and wire sizes. As the industry’s only USCAR 050 selected interface, these high-performing products provide secure connections in limited space applications.
Resources
| Spotlight Products | Description | Mates With | Use With |
|---|---|---|---|
| 34826-8160 | Mini50 Unsealed Right-Angle Header, Dual Row, 16 Circuit, Polarization Option A, 2.80mm Pin Length | 34824-0164 | 560023-0421 |
| 34912-8080 | Mini50 Unsealed Header, Right-Angle, SMT, Single Row, 8 Circuits, Tin (Sn) Plating, Polarization Option A | 0347915180 | 560023-0448 |
| 206523-2121 | Mini50 Unsealed Receptacle, Dual Row, UL94-HB, with CPA, 12 Circuits, Polarization Option A | 34826-0124 | 560023-0421 |
Stac64
This stackable connection system provides single and multi-pocket PCB solutions, offering a diverse range of circuit sizes and greatly reducing time-to-market by completely eliminating custom tooling; female connectors feature only pressure-activated design in the industry.
Resources
| Spotlight Products | Description | Mates With | Use With |
|---|---|---|---|
| 34690-0200 | Stac64 Vertical Header Assembly, 20 Circuits, Polarization A, Tray | 34729-0200 | 34803-3211 |
| 31372-1000 | Stac64 Hybrid Receptacle Assembly, 10 Circuit, Polarization A, without CPA | 34695-0100 | 34803-3211 |
| 34690-0080 | Stac64 Vertical Header Assembly, 8 Circuits, Polarization A, Tray | 34729-0080 | 34803-3212 |
stAK50h
Leveraging industry-approved terminal design, the stAK50h Connection System offers unsealed hybrid headers and receptacles to deliver both signal and Ethernet connectivity within a small footprint. The stAK50h unsealed system and stackable features eliminate the need for custom tooling reducing your time to market.
Resources
| Spotlight Products | Description | Mates With | Use With |
|---|---|---|---|
| 200502 | stAK50h Right-Angle Hybrid Header, 12 Circuits | 1600260001 | n/a |
| 2005010121 | stAK50h Vertical Hybrid Header, 12 Circuits, Key 1, Tube | 1600260001 | n/a |
| 160013-3041 | stAK50h 2 Bay Infotainment Hybrid Header, 56 Circuits, Bay A 28 Circuit Header, Key 4; Bay B 28 Circuit Header, Key 1; 2.50mm PC Tail Length, Tube | 1600140001 | n/a |
HSAutoLink
The HSAutoLink interconnect system supports the bandwidth needed for advanced infotainment, telematics and camera devices for the transportation industry with data rates up to 13 Gbps in robust, sealed and cost-competitive options.
Resources
HFM
The HFM (High-speed FAKRA Mini) coaxial cable solution delivers the design flexibility and features you need for complex ecosystems in tight spaces. These products are available in both sealed and unsealed options as well as vertical and right-angle configurations to reduce your footprint by up to 48%.
Resources
Interconnect Solutions for Transportation Applications
The transportation kit from Molex is packed with samples of DuraClik, MX150 and Stac64 connectors. Learn how these rugged connectors accelerate your design.
Zonal Architecture: Making the Car of the Future Possible
Zonal architecture and the efficiencies it provides will change the face of vehicle manufacturing. Learn how Molex "connects the zones"
DownloadAchieving Zonal Architecture
Connections are key to the cars of the future
Learn MoreConnectivity and electrification in future vehicle design
The automotive industry challenges engineers to pack more systems into each vehicle while reducing weight and increasing efficiencies. Learn about miniaturization, infotainment expansion; advanced micro solutions; ruggedization.
