High frequency connector for 5G
With over 50 years’ experience in the industry, Johnson offers one of the most comprehensive ranges of RF connectors on the global market and has been leveraging its experience and resources to develop and extend its product range to meet the evolving demands of the 5G market.
In response to the changing market needs, driven by the 5G roll-out, Johnson have been actively launching a number
of new products to support higher frequencies and smaller sizes, including:
• 2.92mm family up to 40 GHz
• 2.4mm family up to 50 GHz
• 1.85mm family up to 67 GHz
• SMP family expansion up to 40 GHz
• SMPM family expansion up to 65 GHz
• Ganged SMP 4 Port up to 40 GHz
• SMP3 family up to 67 GHz
• 1.0mm family up to 110 GHz
Johnson’s extensive range of 50-Ohm connectors are rated up to 110 GHz and are available in brass or stainless steel, with support for a number of configurations including P.C. board mount (thru-hole and surface mount), End Launch, Bulkhead Flan ge Mount and Cable.
Features
- Self-contained, no external mounting screws, adapter sections, spring clips.
- Center contact pin does not require special orientation to the surface of the circuit board.
- Output coax matches the thickness of the high frequency board substrate.
- Signal side grounding legs to keep grounding paths short.
- Perfectly prevent signal cross-talk effects in the transition area.
- New distinctive through hole mounting technique allows varying circuit board thicknesses.
- Appropriate sized connectors do not require additional compensation.
- 45-degree and 30-degree special angle available for limited space.
- Non-magnetic version available.
Applications
- 5G Testing Equipments
- Automated Test Equipment in IC manufacturing
- 5G Networking Infrastructures
- Smart Remote Devices
- Wireless Infrastructure Antennas
- Vehical Radar System under 5G
- Remote Sensing and Metering
- Global Positioning Satellite Antennas
- Industril Radar Systems
- High Speed Routers and Switches
