ICP2840-Power-Amplifier

Microchip’s ICP2840 is a Ka Band MMIC power amplifier fabricated using GaN SiC technology.

It achieves 39.5 dBm saturated output power from 27.5 – 31 GHz, with 22% PAE and 22 dB small signal gain. The balanced topology
provides excellent broadband input and output match to 50Ω and DC blocking capacitors ensure simple integration.

Excellent linearity characteristics make ICP2840 well suited to applications in Satellite Communications. The die are
100% DC and RF tested on wafer ensuring compliance to the electrical specifications.

Features

• Frequency range: 27.5 – 31 GHz
• Pout: 39.5 dBm (Pin = 24 dBm)
• PAE: 22% (Pin = 24 dBm)
• Small Signal Gain: 22 dB (28 GHz)
• Return Loss: 15 dB
• Drain Bias 24V, IDQ = 112 mA – 224 mA
• Technology: GaN on SiC
• Lead-free and RoHS compliant
• Dimensions: 3.025 mm × 3.405 mm × 0.10 mm

Applications

• Satellite Communications
• Aerospace & Defense
• 5G
