i.MXRT1050 Evaluation Kit based on NXP Solution

The i.MX RT1050 EVK is a 4-layer through-hole USB-powered PCB. At its heart lies the i.MX RT1050 crossover MCU, featuring NXP's advanced implementation of the Arm Cortex-M7 core. This core operates at speeds up to 600 MHz to provide high CPU performance and great real-time response. Support for FreeRTOS available within the MCUXpresso SDK.
