USB Type-C Connectivity based on Nexperia Solution

USB Type-C has become the standard USB connector for a multitude of applications, offering both high-speed data transfer and fast and efficient battery charging. In fact, USB Power Delivery (PD) has become an almost universal charging standard in both the smartphone and laptop markets, meaning USB-C plugs and cables are increasingly common. But mixing power with data requires a range of ESD protection solutions, each optimised to their specific task and data rate (10 Gbit/s Superspeed or High-speed for auxiliary data and audio).
